Class 150 Bronze 5K Gate Valves Open Close Indicator ມາດຕະຖານການທົດສອບ: JIS F7400-1996Test Pressure: Body-1.05Mpa, Seat-0.77Mpa Main Material: 1-Body: Bronze (BC6)2-Bonnet: Bronze (BC6)3-Disc: Bronze BC6)4-ລຳ: ທອງເຫລືອງ (C3771BD)5-ແກັສເກັດ: NBR ຫຼືບໍ່ແມ່ນຢາງຫີນ6-Handwheel: ເຫຼັກກ້າ (FC200)
6-Handwheel: ເຫຼັກກ້າ (FC200)
Marine Bronze Gate Valve Class 150 5K
ຫມວດ: JIS Marine Gate Valve
ວັດສະດຸ: Bronze
ມາດຕະຖານ: JIS F7400
ໃບຢັ້ງຢືນ: ໃບຢັ້ງຢືນໂຮງງານ
ລາຄາ Fob: ໄດ້ລາຄາຫຼ້າສຸດໃນປັດຈຸບັນ
ສະຖານທີ່ຕົ້ນກໍາເນີດ: ປະເທດຈີນ
| DN | d | L | D | C | ບໍ່ມີ Bolt | h | t | H | D2 |
| 15 | 20 | 80 | 80 | 60 | 4 | 12 | 9 | 109 | 80 |
| 20 | 25 | 80 | 85 | 65 | 4 | 12 | 9 | 110 | 80 |
| 25 | 25 | 80 | 95 | 75 | 4 | 12 | 9 | 110 | 80 |
| 32 | 39 | 100 | 115 | 90 | 4 | 19 | 11 | 142 | 100 |
| 40 | 39 | 100 | 120 | 95 | 4 | 19 | 11 | 142 | 100 |
| 50 | 50 | 115 | 130 | 105 | 4 | 19 | 12 | 167 | 125 |
| 65 | 62 | 127 | 155 | 130 | 4 | 19 | 13 | 195 | 125 |
| 80 | 74 | 142 | 180 | 145 | 4 | 19 | 15 | 218 | 140 |
| 100 | 100 | 165 | 200 | 165 | 8 | 19 | 15 | 271 | 180 |
